large output sawdust vibration swinging rotary sieve machine wood chip rotary drum screen
The serial chip screen is a special device for wood handing line, mainly used for sorting chips with different size during the chips production process in the paper-making, shaving board, MDF etc industry Its sorting specification could be realized through changing different diameter of meshes. The capacity is 60-380 m³/h The user can choose suitable model according to their need.
| Specifications | |
| Vibratory frequency | 200 rpm |
| Vibratory margin | 20-30 mm |
| Qty of level | 3 level |
| Diameter of hole(upper) | 60 mm |
| Diameter of hole(middle) | 6 mm |
| Sifting area | 10 ㎡ |
| Capacity | 150-200 m³/h |
| Motor power | 11 kw |
| Overall dimensions | L5900 x W3342 x H 2380 mm |
